Control Techniques Commander SE Series User Manual

Commander SE User Guide
Issue Number 5 15
Table 3.21 Commander SE Size 1
Table 3.22 Commander SE Size 2 - 200V, 26A, 1 phase
Table 3.23 Commander SE Size 2 - 200 / 400V, 16A, 3 phase
Table 3.24 Commander SE Size 2 - 200 / 400V, 16A, 3 phase
Table 3.25 Commander SE Size 2 - 200V, 26A, 3 phase
Table 3.26 Commander SE Size 3 - 200V, 30A
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low leakage Low cost Footprint Side
SE11200025 to
SE11200075
4200-6101 Y Y 20
4200-6102 Y Y Y 75
4200-6103 Y Y Y 15
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low leakage Low cost Footprint Side
SE2D200075 to
SE2D200220
4200-6201 Y Y Y 100
4200-6204 Y Y 50
4200-6205 Y Y Y 15
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low leakage Low cost Footprint Side
SE2D200075 to
SE2D200220
4200-6202 Y Y Y 100
4200-6304 Y Y 15
4200-6207 Y Y Y 45
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low leakage Low cost Footprint Side
SE23400075 to
SE23400400
4200-6202 Y Y Y 100
4200-6304 Y Y 15
4200-6207 Y Y Y 20
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low leakage Low cost Footprint Side
SE23200400 4200-6203 Y Y Y 100
4200-6303 Y Y 15
4200-6209 Y Y Y 45
Used with Filter Part
No
Filter Type Mounting Max motor
cable length
(m)
Standard Low cost Footprint Side
SE33200550 to
SE33200750
4200-6302 Y Y Y 100
4200-6303 Y Y 15
