Commander SE User Guide
38 Issue Number 5
6.7 Unlocking a security code
1. Select a parameter to be edited
2. Press the MODE key. The right hand display will flash CodE
3. Press the or keys to set the security code. The left hand display will
show Co
4. Press the MODE key.
5. If the security code has been entered correctly then the display will show
Parameters can now be adjusted
6. If the security code has been entered incorrectly then the display will go back to
Parameter View mode
7. Go back to point 2 and enter the correct security code.
8. To relock the security code, set parameter 10 to Loc and press the STOP/RESET
key.
6.8 Set security back to zero (0) - no security
1. Unlock the previously entered security code using the previous procedure.
2. Set parameter 10 to L2.
3. Go to parameter 25
4. Press mode key 4 times. This saves the security code to the value 0
5. Set parameter 10 to Loc and press the STOP/RESET key.
If the security code has been lost or forgotten, please contact your local Drive
Centre or Distributor.
6.9 Setting to default values
To set the Drive back to default values, set parameter 29 to Eur to load 50Hz defaults
or USA to load 60Hz defaults. Press the MODE key and then the STOP/RESET key
for 1 second. When the default parameters have been set, the display will show the
status of the Drive and the parameter number will return to 01.
6.10 Level 1 and level 2 parameter descriptions
6.10.1Parameter codes/limitations
The key to the parameter codes/limitations in the following Tables is listed below:
1 RW R
ead/Write
2 RO R
ead Only
3 Bit Two state only parameter, OFF or ON
4 B B
ipolar - can have positive or negative values
5 U U
nipolar - can have positive values only
6 T Parameter value is represented on the display with a string of T
ext
7
R Reset required to implement change
8 S S
aved on power down
0.0
01
CodE
01
5
Co
0.0
01
0.0
01
Loc
10
NOTE
