M’Ax User Guide 73
Issue Number: 4
9.9 Menu 10 parameters
Status and diagnostic information
Trip log
Braking control
Parameter
Range(
ô
)Default(
ð
)
Type
10.01 Drive healthy indicator 0~1 RO Bit P
10.02 Drive running indicator 0~1
RO Bit P
10.03 At zero speed indicator 0~1
RO Bit P
10.05 Below set speed indicator 0~1
RO Bit P
10.06 At speed indicator 0~1
RO Bit P
10.07 Above set speed indicator 0~1
RO Bit P
10.11 Braking active indicator 0~1 RO Bit P
10.12 Braking-resistor overload alarm indicator 0~1
RO Bit P
10.15 ac supply loss indicator 0~1 RO Bit P
10.17 {0.39} Motor [I2t] overload alarm indicator 0~1
RO Bit P
10.18 Heatsink temperature alarm indicator 0~1
RO Bit P
10.19 Alarm indicator 0~1 RO Bit P
10.20 {0.44} Last trip
RO Txt S P
10.21 Second last trip
RO Txt S P
10.22 Third last trip
RO Txt S P
10.23 Fourth last trip
RO Txt S P
10.24 Fifth last trip
RO Txt S P
10.25 Sixth last trip
RO Txt S P
10.33 Drive reset 0 ~ 1
RO Bit
10.38 User-defined trips 0 ~ 255 0 RW Uni
10.39 {0.42} Internal braking-resistor overload accumulator 0 ~ 100.0 %
RO Uni P
10.40 Status word 0 ~ 32767
RO Uni P
10.41 Trip-0 time (years, days) 0.000 ~ 9.365 y.d
RO Uni P
10.42 Trip-0 time (hours, minutes) 00.00 ~ 23.59 h.m
RO Uni S P
10.43 Trip-1 time (hours, minutes) 00.00 ~ 600.00 h.m
RO Uni S P
10.44 Trip-2 time (hours, minutes) 00.00 ~ 600.00 h.m
RO Uni S P
10.45 Trip-3 time (hours, minutes) 00.00 ~ 600.00 h.m
RO Uni S P
10.46 Trip-4 time (hours, minutes) 00.00 ~ 600.00 h.m
RO Uni S P
10.47 Trip-5 time (hours, minutes) 00.00 ~ 600.00 h.m
RO Uni S P
10.52 SLM technology failure indicator 0~512
RO Uni P
10.53 Under-voltage protection disable 0~1 0 RO Bit P
10.54 AC-supply phase failure protection disable 0 ~ 1 0 RO Bit
10.55 Internal braking-resistor protection disable 0~1 0 RW Bit
10.56 {0.41} Drive overload accumulator 0.0 ~ 100.0 %
RO Uni P
10.57 Supply interlock 0 ~ 1
RO Bit P
10.58 {0.40}
Motor I
2
t accumulator
0.0 ~ 100.0 %
RO Uni P
10.59 SLM pcb temperature 0 ~ 100
°C RO Uni P
10.60 Motor winding temperature 0 ~ 220
°C RO Uni P
