Control Techniques Unidrive 1401 User Manual

Safety
Information
Product
Information
Mechanical
Information
Electrical
Information
Getting
Started
Menu 0
Running
the motor
Optimisation Macros
Advanced
Parameters
Technical
Data
Diagnostics
UL Listing
Information
200 Unidrive User Guide
www.controltechniques.com Issue Number: 9
L1.SYNC Synchronisation to the AC supply failed
39
Regeneration sinusoidal rectifier failed to synchronise to the AC supply.
Ensure that the AC supply voltage and frequency are within the specified limits.
Ensure power connections are correct.
OA Control PCB over temperature
23
The ambient temperature around the control PCB has reached the over temperature threshold of 95°C (203°F) (see the Air alarm).
Check cubicle / drive fans are still functioning correctly
Check cubicle ventilation paths
Check cubicle door filters
Check ambient temperature
Reduce drive switching frequency
Oh1 IGBT junction over temperature (based on the drive thermal model)
21
IGBT junction temperature (based on the drive’s thermal model) has reached the over temperature threshold of 145°C (293°F) and
the drive was unable to reduce the switching frequency further. Pr 7.32 displays the estimated IGBT junction temperature calculated
by the drive.
Reduce drive switching frequency
Reduce duty cycle
Decrease acceleration / deceleration rates
Reduce motor load
Oh2 Heatsink over temperature
22
Heatsink temperature (detected by thermistor) has reached the over temperature threshold of 94°C (201°F) (see the hot alarm).
Check cubicle / drive fans are still functioning correctly
Check cubicle ventilation paths
Check cubicle door filters
Increase ventilation
Decrease acceleration / deceleration rates
Reduce drive switching frequency
Reduce duty cycle
Reduce motor load
OI.AC Over Current in output stage
3
Over current threshold on the output of the drive, of 225% of the drive’s Full Load Current (FLC), has been reached. (The FLC of the
drive is displayed in Pr 11.32)
This can be caused by the following:
•Pr 0.03 Acceleration rate set too low
•Pr 0.04 Deceleration rate set too low
• Short-circuit at the output of the drive
• Break-down of motor insulation (check with Megger)
• Incorrect motor map values see section 7.2 Quick Start commissioning on page 84 for details on how to enter the motor map
• Excessive motor-cable length (increased cable capacitance charging current)
• CL> Loss of speed feedback signals
• CL> Noise on speed feedback signals
• CL> Loose mechanical coupling on speed feedback device
•CL> Reduce the values in the speed loop gain parameters (Pr 3.10, Pr 3.11 and Pr 3.12)
•CL> Reduce the values in the current loop gain parameters (Pr 4.13 and Pr 4.14)
• SV> Phase offset value incorrect (Encoder Pr 3.28, SINCOS encoder and Resolver Pr 16.09). Perform a phase offset test, see
section 7.2.3 Servo on page 86 for more information.
• OL & VT> If this trip occurs during an autotune (sometimes with large motors), decrease the voltage boost value in Pr 5.15.
OI.AC n Over current in the output stage of module n
118 to 125
Over current threshold in the output of the stage of module n of 170% of the drive’s Full Load Current (FLC), has been reached (size
5 only).
This can be caused by the following:
•Pr 0.03 Acceleration rate set too low
•Pr 0.04 Deceleration rate set too low
• Short-circuit at the output of the drive
• Break-down of motor insulation (check with Megger)
• Incorrect motor map values see section 7.2 Quick Start commissioning on page 84 for details on how to enter the motor map
• Excessive motor-cable length (increased cable capacitance charging current)
• CL> Loss of speed feedback signals
• CL> Noise on speed feedback signals
• CL> Loose mechanical coupling on speed feedback device
•CL> Reduce the values in the speed loop gain parameters (Pr 3.10, Pr 3.11 and Pr 3.12)
•CL> Reduce the values in the current loop gain parameters (Pr 4.13 and Pr 4.14)
• SV> Phase offset value incorrect (Encoder Pr 3.28, SINCOS encoder and Resolver Pr 16.09). Perform a phase offset test, see
section 7.2.3 Servo on page 86 for more information.
• OL & VT> If this trip occurs during an autotune (sometimes with large motors), decrease the voltage boost value in Pr 5.15.
Trip Diagnosis
