Convaid Cruiser - Seat Back Height Measurement; Seat Width Measurement

Proper seat width enables the user to sit comfortably and
prevents problems from developing. While user is seated on
a flat surface, measure from hip to hip. Fig. 25
The user should have enough room to prevent hips and
thighs from rubbing against the frame. However, the chair
should not be too wide or the user will slide around and
posture could be affected.
8
Seat Back Height
Seat Width
Fig.26
Seat back height varies according to chair type and seat
width. Headrest extensions are available when extra height
is needed to support the head.
To determine the seat back height, measure from the seat to
the top of the shoulder or the upper part of the head.
Fig. 24
The seat width measurement for the EZ Rider,
Convertible,
and Safari T
ilt
is taken from the actual
seat width.
Fig.24
Fig.25
Seat back height
FITTING GUIDE
The seat width measure-
ment for Cruiser, Scout
and Metro is taken from
the inside of the armrest
tubes. Fig. 26
