CONVAID USER’S GUIDE
19
Rear Anti-tip Tubes
Removable anti-tip tubes prevent chair from tipping.
To attach, remove the bolt near the open end of the anti-tip tube. Slide the anti-tip tube
over the short tube that is located next to the rear tire.
Fig. 71 Align the holes on the
anti-tip tube and the short tube and insert the bolt from the side away from the tire.
Thread the washer and nut onto the bolt once it is all the way through both tubes. Tighten
with wrenches provided. Fig. 72 Repeat for other side.
Utility Bag
The Utility Bag is for storing essential
items. It attaches to the back of the
chair, but can be removed and converted
to tote bag. Fig. 73 & 74
To attach:
1. Hook clasps onto rings.
Fig.73
Fig.71
Fig.72
Fig.74
