Convaid Cruiser - Mounting Convertible Large Wheels

2
1. To install wheels, lift
frame at rear legs.
2. Depress button on quick
release axle.
3. Push wheel axle into the
axle housing on frame
until a click is heard.
Fig. 7
Caution: Pull wheel in
opposite direction of
attachment to ensure
axle is properly
attached to frame.
!
SETTING UP
Fig.7
Fig.5a
Fig.5b
Mounting Convertible Large Wheels
Fig.6a
Fig.6b
