Convaid Cruiser - Operating Tilt and Recline Functions

SAFARI TILT
26
Fig.91
Fig.92
Fig.93
Tilt and Recline
6. Lean chair
backward on
rear wheels and
push on front legs
to complete fold.
Fig. 91
For best results,
have front casters
in trailing position.
Fold footrest
down. Fig. 92
7. Fasten closure
strap.
Caution:
Keep fingers
free of folding
mechanism.
To Tilt:
If chair has both tilt & recline options,
release lock by squeezing trigger on
left handle. Tilt to desired angle and
release triggers.
If chair has tilt only, release lock by
squeezing trigger on both handles.
Tilt to desired angle and release
triggers.
To Recline:
Release lock by squeezing trigger
on right handle. Pull back on both
handles and release triggers.
Recline option not available on
SFT18. Fig. 93
!
Note: For optimal use, lubricate
the silver tilt tubes (Mechlocks)
every 3 months.
