Convaid Cruiser - Planar Seat and Back; Attaching Planar Seat to Cruiser

29
CONVAID USER’S GUIDE
Planar Seat and Back
Attaching Planar Seat
To attach the solid planar seat:
1. First remove the fabric seat by first detaching it from
the Velcro pad on the back of the chair. Fig. 100
2. Slide the seat out by pressing the release buttons on
the outside of the telescoping tubes and pulling on the
tubes. Set unit and tubes aside. Fig. 101
3. Remove the telescoping tubes from the planar seat.
Fig. 102 (These tubes are shipped attached to the
planar seat and have the release button on the inside
of the tubes.)
4. Insert telescoping tubes into the chair frame with
release buttons to the inside. Adjust seat depth by
pressing a release button and sliding the tube until it
clicks into position. Fig. 103
• Cruiser
Fig.100
Fig.101
Fig.102
Fig.103
