WHEEL LOCKS
22
Locking and Unlocking
Convaid manufactures two types of wheel locks: hand operated
and foot operated. Check to see which type of wheel locks are on
your chair.
Fig.79 Unlocked Fig.81 Unlocked
Fig.78 Locked Fig.80 Locked
To lock, pull down on handle.
Fig. 78
To release lock, pull up on handle.
Fig. 79
Wheel Locks
To lock, use foot to press the
front of lever until locked. Fig. 80
To release lock, use foot to push
down on rear of the lever. Fig. 81
Hand Wheel Locks
Foot Wheel Locks
