CONVAID USER’S GUIDE
15
Headrest Extension
Headrest extension fits easily into sockets on seat back. Fold chair slightly. Move rubber
grommets on the mounting posts to adjust height of seat back extension. Fig. 49 & 50
Fig.49
Fig.50
Foam Wedge
Use the foam wedge to modify seating or positioning or to correct posture in any Convaid
chair. Fig. 51, 52, 53 & 54
Fig.51
Fig.53
Fig.52
Fig.54
Note: To reduce the
possibility of injury, the
headrest extension must
be used with transit
models.
Padded Headwings
Adjustable padded headwings provide soft foam support for midline positioning. Fig. 47
The padded headwings can be attached at any height by wrapping the Velcro®
straps around the frame and attaching at the back of the chair. Secure headwings by tying
laces through the grommet holes in the back of the seat fabric or headrest extension.
Fig. 48
Fig.48Fig.47
