2-4 Appendixes Timing chart No.1 Paper feed from drawer, single-side mode, original size A4/11" x 8 1/2", two sheets
PFCL
Primary feed Scondary feed Primary feed Scondary feed105 ms 250 ms 105 ms 250 ms
RSW RM Dev.BIAS
Separation charging Transfer charging
ESW
YC8-3
YC8-9 YC4-4
YC9-7 YC9-11
YC15-2
430 ms 430 ms
150 ms
330 ms
320 ms
150 ms
290 ms 290 ms
10 ms
670 ms10 ms
2020 ms
100 ms
1900 ms (16cpm machine)
1810 ms (20cpm machine)
