9. BASIC PROCEDURES - USE
RISK OF CRUSHING:
Some parts of the machine, such as demounting/mounting
head, bead breaker, turntable, tilting pole, move and can
create a potential crushing point.
Keep your hands and other body parts away from moving
parts of the machine.
RISK OF IMPACT:
Tilting of the operating arm can create a
potential risk of impact with parts of the body.
The tilting operation must be performed
in position B
WARNING
WARNING
12a
12b
AVOID ANY PHYSICAL DAMAGE
Before carrying out maintenance
on the machine:
1. Put the machine in a stable
configuration with the horizontal
axis completely retracted and the
pole in working or resting position (Fig. 12c).
2. Disconnect the power supply plug (Fig 12a).
3. Isolate the compressed air line by
disconnecting the closing valve (quick release
connector) (Fig. 12b.)
12c
