8. MAIN WORKING ELEMENTS OF THE
MACHINE
Learn your machine: knowing exactly how the machine works is the best way to guarantee
safety and machine performance.
Learn the function and layout of all controls.
Carefully check that all controls on the machine are working properly.
To avoid accidents and injury, the machine must be installed properly, operated correctly
and serviced regularly.
WARNING
1 Clamping handle: at 2 positions
- Z position button for tool head and
horizontal axis unlocked
- Y position button for tool head and
horizontal axis locked
2 Vertical and horizontal arm (to position
the mounting/ demounting tool).
