Appendix G—Troubleshooting Guide
In diagnosing pump and system troubles, record the
following data during product transfers:
1. Pressure at pump suction.
2. Pressure at pump discharge.
3. Pressure in truck tank.
4. Pressure in tank being lled.
5. Pipe size and length of suction and discharge lines.
6. Size and length of vapor equalizing line.
7. Pump speed if practical.
Problem Cause Solution
Low capacity Pump speed too slow Check engine speed and PTO on pulley ratio. Consult pump
performance curve. Use tachometer on pump if speed is
questionable.
High differential pressure Restriction in discharge piping or hose too small. Vapor
equalization lines too small or not used.
External bypass valve stuck
open or set too low
Readjust, repair, or replace valve.
Clogged strainer Clean strainer.
1,450 RPM Motor
Motor
Hp
Nominal
Pump RPM
1,750 RPM Motor
Belt
Number
Sheave Pitch Diameter Sheave Pitch Diameter
Belt
Number
Pump Motor Pump Motor
3VX690 QD3/3V14.00 QD3 /3V4.12 7. 5 420 QD3/3V19.00 QD3/3V4.75 3/3V800
3VX710 QD3/3V14.00 QD3/3V4.50 470 QD2/3V19.00 QD2/3V5.30 3VX800
3VX710 QD3/3V14.00 QD3/3V5.00 520 QD3/3V14.00 QD3/3V4.12 3VX690
3VX630 QD3/3V10.60 QD3/3V4.12 580 QD3/3V14.00 QD3/3V4.50 3VX710
3VX650 QD3/3V10.60 QD3/3V4.75 640 QD2/3V14.00 QD2/3V5.30 3VX710
2/3VX710 QD2/3V14.00 QD2/3V6.90 710 QD3/3V10.60 QD3/3V4.50 3V650
3VX650 QD2/3V10.60 QD2/3V5.60 780 QD2/3V14.00 QD2/3V6.50 2/3VX710
3VX600 QD3/3V8.00 QD3/3V4.75 860 QD2/3V10.60 QD2/3V5.30 3VX650
3VX580 QD3/3V6.90 QD3/3V4.50 950 QD2/3V10.60 QD2/3V6.00 3VX670
3VX690 QD3/3V14.00 QD3 /3V4.12 10 420 QD3/3V14.00 QD3/3V3.35 3VX690
3VX710 QD2/3V14.00 QD2/3V4.75 470 QD3/3V14.00 QD3/3V3.65 3VX690
3VX710 QD2/3V14.00 QD2/3V5.00 520 QD3/3V10.60 QD3/3V3 .15 3VX616
3VX710 QD2/3V14.00 QD2/3V5.60 580 QD2A15.6/B16.0 QD2A4.8/B5.2 2/B72
3VX650 QD2/3V10.60 QD2/3V4.75 640 QD2A15.0/B15.4 QD2A5.0/B5.4 2/B71
3VX650 QD2/3V10.60 QD2/3V5.30 710 QD1A15.6/B16.0 QD1A6.0/B6.4 B74
3VX570 QD3/3V6.90 QD3/3V3.65 780 QD2/3V10.60 QD2/3V4.75 3VX650
3VX600 QD2/3V8.00 QD2/3V4.75 860 QD2/3V10.60 QD2/3V5.30 3VX650
3VX580 QD2/3V6.90 QD2/3V4.50 950 QD3/3V6.00 QD3/3V3.35 3VX550
3/3VX800 QD3/3V19.00 QD3/3V5.60 15 420 QD3/3V25.00 QD3/3V6.00 3/3V900
3/3VX800 QD3/3V19.00 QD3/3V6.00 470 QD3/3V19.00 QD3/3V5.30 3VX800
3V830 QD3/3V19.00 QD3/3V6.90 520 QD3/3V19.00 QD3/3V5.60 3/3VX800
3VX710 QD3/3V14.00 QD3/3V5.60 580 QD3/3V19.00 QD3/3V6.50 3V810
3V730 QD3/3V14.00 QD33/3V6.00 640 QD3/3V14.00 QD3/3V5.30 3/3V710
3/3VX710 QD3/3V14.00 QD3/3V6.90 710 QD3/3V14.00 QD3/3V5.60 3VX710
3VX650 QD3/3V10.60 QD3/3V5.60 780 QD3/3V10.60 QD3/3V4.75 3VX650
3/3VX670 QD3/3V10.60 QD3/3V6.50 860 QD3/3V10.60 QD3/3V5.30 3VX650
3/3VX670 QD3/3V10.60 QD3/3V6.90 950 QD3/3V10.60 QD3/3V6.00 3VX670
B78 QD3A18.0/B18.4 QD3A6.0/B6.4 20 520 QD3A18.0/B18.4 QD3A5.0/B5.4 3/B77
B73 QD3A15.0/B15.4 QD3A6.2/B6.6 640 QD3A18.0/B18.4 QD3A6.0/B6.4 3/B78
B68 QD3A12.0/B12.4 QD3A6.2/B6.6 780 QD3A15.0/B15.4 QD3A6.4/B6.8 3/B73
B65 QD3A10.6/B11.0 QD3A6.0/B6.4 860 QD3A13.2/B13.6 QDA6.2/B6.6 3/B70
B78 QD4A18.0/B18.4 QD4A6.0/B6.4 25 520 QD3/5V18.70 QD3/5V5.50 3/5VX800
B80 QD3A18.0/B18.4 QD3A7.6/B8.0 640 QD3A18.0/B18.4 QD3A6.2/B6.6 3/B78
B75 QD3A15.0/B15.4 QD3A7.6/B8.0 780 QD3/5V10.90 QD3/5V4.90 5VX650
B72 QD3A13.2/B13.6 QD3A7.6/B8.0 860 QD3A13.2/B13.6 QD3A6.2/B6.6 3/B70
Appendix F—V-Belt Selection for the Z4500
G. Troubleshooting Guide
