Mounting ange 2 bolt SAE A
Input shaft
1 in. diameter
straight keyed
Port ‘A’ 7/8-14 O-ring
Port ‘B’ 7/8-14 O-ring
Pilot diameter
3.250/3.245 in.
(57.15 /57.02 mm)
Motor displacement
6.2 cubic in. per
revolution
Maximum speed continuous duty 742 RPM
Flow continuous duty 20 gpm (76 L/min)
Torque continuous duty
3,500 in•lb
(395.5 N•M)
Case drain 7/16-20 O-ring
Recommended uids
Premium quality
anti-wear
Minimum viscosity 70 SSU (13 cSt)
Maximum operating temperature 180°F (82°C)
Appendix H—Storage of the
Z-Series Coro-Vane
®
Pump
If your Corken Z-Series pump is to be removed from
service for some time, the pump must be protected
as propane, butane and anhydrous ammonia all leave
the metal “bare” and open to corrosion. Piping and
tanks not in service should also be protected, as the
rust particles can destroy the pump’s seals almost
immediately after startup.
1. Fill or thoroughly ush the pump with a light rust
inhibiting oil. (If the pump is ushed with oil, placing
some desiccant packets inside the pump will provide
added protection.)
2. Plug all pump openings.
3. Store in a dry location.
4. Before placing the pump back into service, drain the
oil and remove any desiccant packets.
5. Refer to the “OPERATION OF YOUR PUMP” section
of this manual.
Appendix I—Hydraulic Motor
Specications
1
Operating Specications for Char-Lynn Hydraulic Motor
1
Data applies to this particular motor only. Your application may vary,
please consult factory for details.
H. Extended Storage
I. Hydraulic Motor Specications
