38 - ORDINARY MAINTENANCE
COROB™ D600 - D700 - D800 EXTRA
7.4 External cleaning
WARNING
NEVER USE WATER OR SOLVENT-BASED CLEANING PRODUCTS TO CLEAN THE MACHINE.
In case the colorant has poured inside the machine, do not try to clean; turn the machine off at once and
contact an authorized service center.
In case of paint spills, clean the machine immediately.
1. Disconnect power supply (chapter 5.8).
2. Clean coverings, panels and control devices
of the machine, to remove dirt, dust and any
colorant stains, using a soft and dry cloth, or
slightly moistened with a mild cleansing solution.
3. Connect power supply and switch on the machine
(chapter 5.3).
See the manufacturer manual for instructions on
cleaning the computer.
Figure 22
7.5 Cleaning the nozzle center
1. Open the Autocap...
Figure 23
I
using the command
in the management
software.
II
bringing the
machine to the off-
line 2 condition,
by means of the
off-line button.
2. Disconnect power supply (chapter 5.8).
3. Accurately clean the nozzles using a sharp tool;
remove any dried colorant residue delicately, to
avoid damaging the ends of the circuits.
4. Connect power supply and switch on the machine
(chapter 5.3).
5. Close the Autocap...
I
it closes automatically
during initialization.
II
bringing the
machine to the
on-line condition,
by means of the
off-line button.
6. Carry out Purge, using the command in the
management software.
