corob D700 extra - Checking and Replacing the Puncher

ORDINARY MAINTENANCE - 41
COROB™ D600 - D700 - D800 EXTRA
7.7 Checking and replacing the puncher
DANGER
TO PERFORM THIS OPERATION YOU MUST WEAR CUT-PROOF GLOVES.
8 mm
To remove the puncher
2 3
4
Dx2
A
B
C
A+BA+B
Figure 26
