SHIPPING, HANDLING AND UNPACKING - 15
4
A
Figure 4
b
a
d
c
Figure 5
5. With one person at the right side and another person on the left side, lift the machine straight up until the
pallet is free and can be removed by the third person.
6. Lower machine feet to support and level the machine properly, and make sure that the wheels are not
resting.
4.3.1 Standard material supplied
After unpacking the machine, make sure the following items are present:
1. Power supply cable. 2. Computer power cables.
3. USB cable. 4. RS232 cable.
5. Spare fuses. 6. Panel key.
7. Spare parts for humidier cap. 8. Equipment software tools standard CD.
9. User’s manual. 10. Adapter for Quart (1-liter) and Pint-size (0.5-liter) cans.
Depending on the options specied on the purchase order, you may also nd:
• Management software and protection key.
• Any accessories to be installed on the machine.
Make sure that all of the above items are included in the packing; if not, contact the manufacturer.
