corob FIRST 70 - Adjusting Can Shelf Height; Loading the Can

24 - USING THE DISPENSER
COROB™ FIRST 70
6.3.1 Adjusting the can shelf height
Keeping the two side buttons pressed, insert the shelf in the appripriate guide based on the size of the can to
be used. Release the two buttons to lock the shelf in place.
Figure 9
WARNING
The shelf position must be such that it allows the can to push the cap bar open.
6.3.2 Loading the can
Place the can on the shelf to push the cap opening
bar inward and thus cause it to open.
Figure 10
6.3.3 Using the adapter
The adapter to position Quart (1-liter) and Pint-size (0.5-liter) cans is made up of two spacers (A and B).
1. Place the shelf at its maximum height.
