Cosman G4 - Pulsed RF Screen

Cosman G4 Radiofrequency Generator Service Manual (SPI 11291 Rev A)
Section 9
Pulsed RF Screen
Set Voltage &
E-dose Settings
E-dose =
Vary Voltage
Output Off
E-dose =
Vary Voltage
Output On
Time
r
: Holds value from
last instance of Pulsed
RF output.
Screen Shot Button:
Save an image of the
screen to the Procedure
Record.
Mode Ba
r
: A
other procedur
screens
ccess
e
Electrode Panel (Black area):
Displays all readings for the
indicated electrode output. When
enabled, RF output is delivered to
this output.
Electrode Setup Indicator
(Section 7.1)
Personal Settings Preset
Indicato
r
Output Off
Indicator
Time
r
: Counts up to Set
Temp in Minutes and
Seconds (min:sec) w
RF output is on.
hen
Impedance reading:
• Held a latest value
(gray color) when
during Stagger S
Reads “
tart.
• --- ” when
Impedance greater
than 3000  (open
circuit
)
.
RF Current Reading: In units
of Peak Milliam
p
s.
Settings Panels:
Lists the current
Pulsed RF settings.
Pulsed RF
Settings
Section 9.2.4
• Change settings
associated with
the target
Settings Panel
Press front-panel or on-screen
Start Button or depress
Footswitch: Pulsed RF output
is delivered to all active
electrodes.
Press front-panel or on-screen
Stop Button, release Footswitch,
timed output completes, or error
occurs: Electrode output is
turned off.
Press a Settings
Panel button
Start/Stop Button:
Press “Start” to turn
electrode output on.
Press “Stop” to turn
electrode output off.
Start/Stop Button:
Press “Start” to turn
electrode output on.
Press “Stop” to turn
electrode output off.
Impedance
Readin
g
Temperature reading:
Reads “-- °C” when
Temperature is less
than 10°C or absent.
RF Voltage Reading:
In units of Peak Volts.
Pulse Rate,
Pulse Width &
E-dose Settings
