33
PUMP GROUP, MIXED DN 25 WITH WEATHER-COMPENSATED ACTUATOR
POSITION KBN DESCRIPTION
1 YCOQ00001 Ball valve DN 25, 2x plug, with device for thermometer
2 YCOQ00002 Union nut G1½", wrench size 52, octagonal
3 YCOQ00003 Gasket for G1½", EPDM, Ø 44.0 x Ø 32.0 x 2.0
4 YCOQ00004 Ball valve handle for thermometer, Ø 50 mm
5 YCOQ00005 Dial thermometer, red, 0-120 °C, Ø 50 mm
6 YCOQ00006 Dial thermometer, blue, 0-120 °C, Ø 50 mm
10 YCOQ00010 Brass pipe with check valve, DN 25, 180 mm x 1½" ext. thread
11 YCOQ00011 3-way T-mixing valve DN 25 with bypass, with mixing valve rotary knob, 1" F x 1½" ext. thread
15 YCOQ00015 Mixing valve rotary knob for actuator CKR6 + CWR6
16 YCOQ00016 Insulation for pump group DN 25 with CKR6 + CWR6, complete set
18 YCOQ00018 Temperature sensor Pt1000-B G¼", cable length 290 mm, C-Grid/SL
25 YCOQ00025 Actuator CWR6, 6 Nm, flow and external sensor Pt1000
48 YCOQ00048 Spare parts set for ball valve DN 25
49 YCOQ00049 Spare parts set for 3-way T-mixing valve DN 25
59 YCOQ00059 Pump insert for insulation, necessary when replacing COSMO CPH by CPH 2.0
* / Pump DN 25, 1½" ext. thread x 180 mm
/ C2WSPG Right-angle plug with 2 m cable, suitable for Grundfos/Wilo pumps
NOTE
Complaints will only be processed with information on the serial number!
The serial number is placed on the return pipe of the pump group.
9 MAINTENANCE
9.1 SPARE PARTS
