1018029-E Page 2
CONTENTS
Before Installation
Standards ........................................... 2
..................................... 3
Introduction ........................................ 3
Safety ................................................. 3
Venting ........................................... 4 - 5
Combustion & Ventilation ................ - 7
Installation
Locations ............................................ 8
...................... 8 - 9
Installing ..................................... 10 - 11
Controls ............................................ 11
.................................. 11
Lighting Instructions .................... 12 - 13
Maintenance
Proper Burner Flame ........................ 14
Operation .......................................... 14
Terminal Block Wiring Diagram ......... 15
........................ 15
Maintenance Instructions .................. 15
Wiring Schematics ............................
Kits:
• 14-PEK Extension Kit ........................ 17
• .............. 18
• ............ 18
•
Side Discharge Kits .......................... 19
Troubleshooting Charts ............... 20 - 23
Installations In The State Of
Massachusetts .................................... 21
Parts
CF Part List ................................ 24 - 27
Warranty ............................................. 28
The State of Massachusetts requires that installation
and service of a gas appliance be performed by a
plumber or gas tter licensed in the Commonwealth of
Massachusetts. See page 21.
These installation instructions are a general guide and do not
supersede applicable local codes and ordinances. Before planning
edition of National Fuel Gas Code, ANSI.Z223.1, or CAN1-B149).
the latest edition of National Electrical Code ANSI / NFPA 70, or
Canadian Electrical Code CSA-C22.1.
All of the ANSI and NFPA standards referred to in these installation
Installer must leave these instructions with the consumer, have
them complete, and return the warranty card.
READ CAREFULLY BEFORE INSTALLING UNIT
NFPA Standards:
NATIONAL FIRE PROTECTION
ASSOCIATION
1 Batterymarch Park
ANSI & Canadian Standards:
CSA GROUP
