COUNTERFLOW WALL FURNACE PARTS LIST
Natural Gas: CF403D-H, CF553D-H, CF407D-H, CF557D-H
Propane Gas: CF404D-H, CF554D-H, CF408D-H, CF558D-H
PART DESCRIPTION
REF. #
PART NO. PART NO. PART NO. PART NO.
Propane Gas Model Numbers ........................
Natural Gas Model Numbers .........................
1 Casing Side, Right 30325 30525 30325 30525
1A Casing Side, Left 30330 30530 30330 30530
1B Center Back Assembly     
1C Top Assembly 30025-80 30025-80 30025-80 30025-80
1D Upper Back Assembly 30070 30070 30070 30070
1E Lower Back Assembly 30219 30219 30219 30219
1F Bottom     
2 Liner Assembly 30370 30550 30370 30550
3 Header Assembly Complete 31399 31399 31399 31399
4 Heat Exchanger Assembly 30378 30581 |    | 
5 Draft Diverter Assembly 30400 30400 30400 30400
6 Fan Shroud Assembly 30200-10 30200-10 30200-10 30200-10
7 Top Louver w/ Insulation 30087 30087 30087 30087
8 Center Front Panel w/ Insulation 30359 30534 30359 30534
9 Bottom Louver Assembly w/ Insulation 30100 30100 30100 30100
10 Upper Front Shield 30250 30250 30250 30250
11 Switch Box 30252 | 30450 30252 | 30450 30252 | 30450 30252 | 30450
12 Switch Box Cover 30253 30253 30253 30253
13 Lower Front Shield     
14 Motor Mounting Bracket *30079 *30079 *30079 *30079
15 Junction Box Cover 30033 30033 30033 30033
19 Wiring Harness 78251 78252 78252 78257
24 Fan Motor 78111 78111 78111 78111
25 Fan Blade 72111 72111 72111 72111
26 Rubber Grommet (Requires 4) **78010 **78010 **78010 **78010
27 Limit Switch     
28 Fan Switch   |   |   |   | 
29 Speed Switch    
30 Auxiliary Limit Switch    
32 Transformer     
32B Flue Pipe Adapte    
32C Plug Bracket 30047 30047 30047 30047
32D Casing Mounting Brackets     
33 Flue Pipe Gasket - 4x8-7/16” 78050 78050 78050 78050
34 Draft Diverter Gasket - 7x8” 78051 78051 78051 78051
34B Casing Top Gasket - 8-1/2x4-1/2” 78155 78155 78155 78155
35 Element Support Gasket - 9-1/2x14-1/4” 78052 78052 78052 78052
37 Cozy Handle 84003 84003 84003 84003
39 Snap-in Outlet 78058 78058 78058 78058
45 Blocked Flue Switch 78107 78109 78107 78109
46 Blocked Flue Switch Wire 78230 78230 78230 78230
