COUNTERFLOW WALL FURNACE PARTS LIST
Natural Gas: CF403D-H, CF553D-H, CF407D-H, CF557D-H
Propane Gas: CF404D-H, CF554D-H, CF408D-H, CF558D-H
* Requires 2 ** Requires 4
PART DESCRIPTION
REF. #
PART NO. PART NO. PART NO. PART NO.
Propane Gas Model Numbers ........................
Natural Gas Model Numbers .........................
STANDING PILOT MODELS IID PILOT MODELS
16 Burner 72107 72107 72107 72107
17 Valve, VR8200H-1004 Natural Gas
w/ 78089 Dis. Bushing 78090 78090 78092 78092
18 Valve, VR8200H-1103 Propane GAS
w/78089 Dis. Bushing 78091 78091 78093 78093
N/A Disappearing Bushing 1/2 x 3/8 78089 78089 78089 78089
21 Manifold     
22 Orice, NATURAL    
23 Orice, PROPANE     
31 Thermostat 24 Volt 78355 78355 78355 78355
36 Pilot, NAT. 0.140.512 72020 72020 - -
36 Pilot, Propane 0.140.502 72021 72021 - -
38 Power Cord 78213 78213 78213 78213
41 Thermostat Wire 49925 49925 49925 49925
42 Thermocouple Q309A1954 78095 78095 - -
43 Insulated Staples 74209 74209 - -
44 Door Catch 80005 80005 - -
47 & 49 Pilot Assy., Electronic w/ Flame Ignitor, Natural - - 78098 78098
48 & 49 Pilot Assy., Electronic w/ Flame Ignitor, Propane - - 78099 78099
50 Ignition Control Box, S8600B - - 78097 78097
52 Terminal Board 78300 78300 78300 78300
53 Burner Pan Assembly     
59 Piezo Sparker     
60 Electrode Wire 72022 72022 - -
57 Pilot Mounting Bracket 30299 30299 30299 30299
58 Burner Mounting Plate     
N/A Valve Support Bracket Assembly 30290 30290 30290 30290
N/A Pilot Tubing w/Fittings - 16” 78452 78452 78452 78452
N/A Lighting Instructions “CF”     
CF404
D-H
CF403
D-H
CF554
D-H
CF553
D-H
CF408
D-H
CF407
D-H
CF558
D-H
CF557
D-H
