Error! Reference source not found.10 lists the parameters for PF Set and
Q(P) Curve modes. Press ENT to start the modes after the parameters are
set.
Table 6-10 Reactive Power Control (IEEE1547-2018、Rule21 and ISO-NE)
Grid Reactive Power Derating
Setting Range
Parameter
name
Description
IEEE1547-2018
Rule21
ISO-NE
Min
Default
Max
Min
Default
Max
Min
Default
Max
QPCurveP1
(%)
Active power of Q(P)
Curve point 1
0
20
100
0
20
100
0
20
100
QPCurveQ1
(%)
Reactive power of Q(P)
Curve point 1
-66
0
66
-66
0
66
-66
0
66
QPCurveP2
(%)
Active power of Q(P)
Curve point 2
0
50
100
0
50
100
0
50
100
QPCurveQ2
(%)
Reactive power of Q(P)
Curve point 2
-66
0
66
-66
0
66
-66
0
66
QPCurveP3
(%)
Active power of Q(P)
Curve point 3
0
100
100
0
100
100
0
100
100
QPCurveQ3
(%)
Reactive power of Q(P)
Curve point 3
-66
-44
66
-66
-44
66
-66
-44
66
QpCurveRs
pTms(s)
Response time of of
Q(P)Curve
0
1
10
0
1
10
0
1
10
6.2.7 Arc Parameters
ARC Parameters is used to enable/disable the ARC function and set the
ARC parameters. These settings are only to be changed by CPS personnel
with approval from the AHJ.
