18
Table 3-2 Accessory Kit
No.
Item
Q’ty
Note
(1)
M6 X18mm Phillips
screw
12
4 for securing the wiring box to the
main enclosure; 6 for securing the
inverter to the mounting bracket; 1 for
the External Ground connection, 1
spare
(2)
5 pin PCB connector
plug
1
For the RS485 communication (Input)
(3)
3 pin PCB connector
plug
1
For the RS485 communication
(Output)
(4)
M8 Nut
4
For the AC terminal block
(5)
M8 Flat washer
4
For the AC terminal block
(6)
M8 Spring washer
4
For the AC terminal block
(7)
Phillips screw
1
Spare (for wire-box cover)
INSTRUCTION:
Additional accessories for the CPS 25kW-208V inverter are available
and can be purchased separately.
