23
a.) NO SHADE COVER REQUIRED
SHADE COVER
b.) SHADE COVER REQUIRED
c.) NOT > 90° TILTED FORWARD
d.) NOT UPSIDE DOWN
>15
o
Figure 3-2 Inverter Mounting Options
