CPS SCA25KTL-DO/US-208 - Page 93

87
MinTripT(s)
The trip time of the
Min grid voltage of
moving average
filter
0
600
655
0
600
655
0
600
655
Grid Voltage Balance
GridVolUnba
lance
Threshold value of
grid voltage
imbalance
0.01
10
10
0.01
10
10
0.01
10
10
PhaseLoseC
oeff
The trigger value of
Zig-Zag protection
0.5
3
30
0.5
3
30
0.5
3
30
PhaseLoseR
cvCoeff
The recovery value
of Zig-Zag
protection
0.5
2
30
0.5
2
30
0.5
2
30
PhaseLoseV
Unbalance
Threshold value of
Zig-Zag voltage
imbalance
0.01
10
10
0.01
10
10
0.01
10
10
Phase-
PETripVolt
(%)
The trigger voltage
value of Phase-to-
ground
0.01
45
100
0.01
45
100
0.01
45
100
Phase-
PERcvVolt
(%)
The recovery
voltage value of
Phase-to-ground
0.01
35
100
0.01
35
100
0.01
35
100
