11
Circuit Wiring
电路接线
X Stepper
X轴电机
Y Stepper
Y轴电机
Z Stepper
Z轴电机 挤出电机0
E0 Stepp
X
Y
Z
Power Supply
电源输入口
Fans
常开风扇
ecafretnI devreseR
预留接口
LCD Displayer
LCD显示屏接口
Limit Switch
X/Y/Z限位开关
Mini USB Port
Mini USB接口
TF Card
TF卡槽
Nozzle2 Thermistor
喷头2热敏电阻
Nozzle1 Thermistor
喷头1 热敏电阻
Hot Bed
热床
Nozzle 1
喷头 1
Nozzle 2
喷头 2
Controlled Fans
可控风扇
Touch Screen
触摸屏
Bed Thermistor
热床热敏电阻
E1 Stepper
挤出电机1
