3
Cable Connection
设备接线
1.Connect the 6pin (4-wire) ports to Z1 and Z2 stepper motors as shown in the figure. 1.按图示将6pin (4线) 端口分别连接Z1、Z2步进电机。
2. Connect the cable to the cable socket on the adapter board. 2.将排线连接到转接板上的排线插座。
Ribbon Cable
排线
Z2
Z1
