Creality Ender-3 V3 SE User Manual

3. Assembly Procedure
3.1 Gantry Frame
① Place the gantry frame in the slot of the base, tighten it first with M3*14 screws by aligning with the holes from the bottom, then use M3*8 screws to secure
it in place from the rear end of the gantry frame in the same way.
Bottom view
03
Use M3*8 screws
Use M3*14 screws

Creality Ender-3 V3 SE Specifications

General

Build Volume	220 x 220 x 250 mm
Layer Resolution	0.1 - 0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Supported Materials	PLA, PETG, TPU
Bed Temperature	Up to 100°C
Nozzle Temperature	Up to 260°C
Extruder Type	Direct Drive
Power Supply	350W
Print Speed	250 mm/s
Connectivity	USB, SD Card
Bed Leveling	Automatic
