Creality K1 Max User Manual

16
5. Functional Specification
5.1 Filament Retreat
Method 1:
① Input the nozzle temperature on the screen and
wait for it to heat up to the target temperature.
② Unlock the extrusion switch. ③Remove the filament from the extruder.
④ Remove the PTFE tube from the top of the extruder.
⑤ Extract the filament from outside the printer.
②
③
④
Note: The current interface is for reference only. Due to the continuous upgrading of
functions, it shall be subject to the latest firmware UI published on the official website.

Creality K1 Max Specifications

General

Build Volume	300 x 300 x 300 mm
Nozzle Diameter	0.4 mm (default)
Filament Diameter	1.75 mm
Connectivity	USB, Wi-Fi, Ethernet
Bed Leveling	Automatic
Print Technology	FDM (Fused Deposition Modeling)
Nozzle Temperature (Max)	300°C
Bed Temperature (Max)	120°C
Acceleration	20000 mm/s²
Chamber Temperature (Max)	60°C
Power Supply	AC 100-240V, 50/60Hz
Printing Speed	600 mm/s
Supported Filaments	PLA, ABS, PETG, TPU
Touchscreen	Yes
