Creality K1 Max User Manual

2. Unboxing
01
04
2.1 Unpacking Steps
Take the packing cotton and tools in the order as shown in figure.
Handle the top cover with care.
(the glass is fragile)
1
2
3
4
Take the touch screen and Power Cable
Move the Extruder to one side in the direction
indicated by the arrow and take the grey foam
as shown in the figure.
5

Creality K1 Max Specifications

General

Build Volume	300 x 300 x 300 mm
Nozzle Diameter	0.4 mm (default)
Filament Diameter	1.75 mm
Connectivity	USB, Wi-Fi, Ethernet
Bed Leveling	Automatic
Print Technology	FDM (Fused Deposition Modeling)
Nozzle Temperature (Max)	300°C
Bed Temperature (Max)	120°C
Acceleration	20000 mm/s²
Chamber Temperature (Max)	60°C
Power Supply	AC 100-240V, 50/60Hz
Printing Speed	600 mm/s
Supported Filaments	PLA, ABS, PETG, TPU
Touchscreen	Yes
