Creality K1 Max User Manual

5. Functional Specification
19
5. Functional Specification
⑨ Reinsert the PTFE tube into the extruder.
⑩ Attach the filament feeding mechanism. ⑪ Lock the extrusion switch.
⑫ Load the filament from outside the printer.
⑬ Click on the “Feed” button.
⑮ Return to the printing page and click the
“Resume Print” button.
⑭ Wait for the filament to start flowing from
the nozzle. The feeding process is complete.
5.2 Change filament
⑨
⑪
⑩

Creality K1 Max Specifications

General

Build Volume	300 x 300 x 300 mm
Nozzle Diameter	0.4 mm (default)
Filament Diameter	1.75 mm
Connectivity	USB, Wi-Fi, Ethernet
Bed Leveling	Automatic
Print Technology	FDM (Fused Deposition Modeling)
Nozzle Temperature (Max)	300°C
Bed Temperature (Max)	120°C
Acceleration	20000 mm/s²
Chamber Temperature (Max)	60°C
Power Supply	AC 100-240V, 50/60Hz
Printing Speed	600 mm/s
Supported Filaments	PLA, ABS, PETG, TPU
Touchscreen	Yes
