1.4 U sing E xam p le

TB2I products can be used inside the elevator shaft to survey the video transmission,

while the use of multiple network interfaces equipped with elevator advertising machine to

real-tim e up d ates . B ac kh aul d ata ne two rks c an rely o n e xisting p ro p e rtie s o r as s e m b ling

outdoor wireless device.

Fig ure 1-1 TB 2 I U s ing E xamp le

1.5 Hardware O verview

H ard wa re info rm atio n o f TB 2I is d e s c rib e d in the fo llo wing Tab le :

Tab le 1-2 Hardware Information

H ard wa re S p e c ific atio ns

C PU /Baseband Radio Atheros QCA9531

M e mory 64MB DRAM, 8MB Flash

P hysic al Interfac e 3×10/100M Base-TX (C at. 5/5E, RJ-45)

P orts

LED LAN, WLAN, 3×Link Q uality

P o we r S u p p ly POE+, Power Adapter 12V
