5 Inch Lectern/Wall Mount Touchpanel Crestron Isys
TPS-2000L
Mounting Options for the TPS-2000L
PRE-CONSTRUCTION
*
OPTION
POST-CONSTRUCTION
**
OPTION
MODEL
NUMBER
DOCUMENT
NUMBER
Back Box Kit - BB-2000L 5973
Pre-Construction Mount Kit - PMK-2000L 6018
Mud Mount Kit (accessory) - MMK-2000L 6025
Trim Mount Kit (accessory) - TMK-2000L 6026
- Wall Mount Kit - Mud WMKM-2000L 6025
- Wall Mount Kit - Trim WMKT-2000L 6026
- Water Resistant Cover TPS-WPK 5993
* Pre-construction refers to framed walls prior to hanging drywall.
** Post-construction refers to framed walls with drywall hung.
If the BB-2000L or PMK-2000L are to be used and a touchpanel is not available, the
installer can either leave the hole in the mounting surface open (if permitted by local
building codes) or attach the cover plate supplied with the mounting kit.
Touchpanel Mounting
Required Tools
#1 Phillips tip screwdriver
1. If the cover plate is attached, use a #1 Phillips screwdriver to loosen and
remove the four screws and plate.
2. Connect all required cables to the touchpanel.
3. Insert the touchpanel (without its faceplate) into the mounting option and
align the four screw holes.
4. Insert and tighten the four supplied screws (finger tight and then using a #1
Phillips screwdriver, tighten an additional 1/8-turn).
5. Insert the ten buttons. If the buttons are engraved, verify that the placement
of the each button matches the programming.
6. Cover the mounted unit with the faceplate. Refer to the illustration after this
paragraph for guidance.
14 • 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L Operations Guide – DOC. 5972A
