5 Inch Lectern/Wall Mount Touchpanel Crestron Isys
TPS-2000L
formats. The unit has a single video input and can display multiple windows when
using a third party display splitter. A light sensor brightens or dims automatically
with changing room light conditions for easy viewing. The result is an outstanding
picture ideal for watching TV, previewing DVDs or checking security cameras. An
optional water-resistant cover provides protection around damp rooms such as the
pool or spa.
The exclusive “virtual pan and zoom” feature in these new Isys
panels is useful and
fun to use. Crestron implemented advanced digital video processor circuitry so that a
touch of the screen with a finger can allow panning across the video picture and
zooming in for the best view – even with standard security cameras.
The audio capabilities of these new Isys wall-mounted touchpanels allow for WAV
sound file storage and playback delivering instantaneous audio feedback, from sound
effects to the sound of one's own voice. A microphone, amplifier and speakers allow
talking with guests, as they are viewed on the security cameras, and adjustments for
volume, bass and treble provide for clear audio.
Specifications
The table below and on the next page provides a summary of specifications for the
TPS-2000L touchpanel.
Specifications for TPS-2000L Touchpanel
SPECIFICATION DETAILS
Power Requirements 13 Watts (0.54 Amp @ 24 VDC)
Default NET ID 03
Timeout
Adjustable from 0 to 120 minutes (Default = 10
min.)
Signal Join Maximums 4000 Digital and Analog, 999 Serial
Control System Update
Files
1,2,3
2-Series Control System Version C2-1008.CUZ or later
CEN/CN-TVAV Version 5.12.63V.UPZ or later
CNMSX-AV/PRO Version 5.12.63X.UPZ or later
CNRACKX/-DP Version 5.12.63W.UPZ or later
ST-CP Version 4.01.04S.UPZ or later
Acceptable File Extensions
4
SIMPL Windows
.smw
.spz
.bin
.csz
projectname.smw (source file)
projectname.spz (compiled file for 2-Series)
projectname.bin (compiled file for CNX generation)
projectname.csz
(compiled file for CNX generation with SIMPL+)
VT Pro-e
.vtp
.vtz
projectname.vtp (source file)
projectname.vtz (compiled file)
Firmware
.csf
TPS-2000.v.xxxxxx.csf (panel firmware)
(continued on next page)
2 • 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L Operations Guide – DOC. 5972A
