TPS-2000L 5 Inch Lectern/Wall Mount Touchpanel
5 Inch Lectern/Wall Mount
Touchpanel: TPS-2000L
5 Inch Lectern/Wall Mount
Touchpanel: TPS-2000L
Introduction Introduction
Features and Functions
The TPS-2000L, compact video touchpanel, is a 5-inch (12.7-cm) active matrix color
display panel with 320 x 234 resolution and 16-bit non-palette graphics. The purpose
of this unit is to provide a single, compact touchpanel that ends the age of walls
cluttered with switches, control panels, thermostats, etc. These wall-mounted panels
can be fully customized for any control environment – graphic icons and 10
programmable “quick” pushbuttons let users easily select and control any function.
The table after this paragraph provides a functional summary of the TPS-2000L.
TPS-2000L Functional Summary
• 5" (12.7 cm) active color matrix display
• 320 x 234 screen resolution
• 16 Bit non-palette graphics
• 2 Mb of Flash & 8 Mb of DRAM memory
• Built-in time-based correction for stable video & graphics
• Balanced/unbalanced composite video input; supports NTSC/PAL
formats
• Full screen video capability
• Up to 4,000 digital and analog signals; up to 999 serial signals
• Built-in microphone & two speakers (half duplex intercom capable)
• that can be programmed for quick access to regularly
used functions*
that can be programmed for quick access to regularly
used functions*
• Stores WAV sound files
• Automatic light sensor
• Capable of inverting image
Ten pushbuttons s
* Custom engraved keys can be ordered separately by using the Crestron Engraver Software. Version
2.0.0.9 or later is available from the Downloads | Software Updates section of the Crestron website
(www.crestron.com
).
The touchpanel is capable of replacing large, complicated panels with a series of
simpler screens; each can monitor and control a specific function. The panel features
balanced and unbalanced composite video input supporting both NTSC/PAL
Operations Guide – DOC. 5972A 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L • 1

Crestron TPS-2000L Specifications

General

Brand	Crestron
Model	TPS-2000L
Category	Touch Panel
Language	English
