Crestron Isys
TPS-2000L 5 Inch Lectern/Wall Mount Touchpanel
Digital Output Signal Descriptions
OUTPUT DESCRIPTION
press 1 through press 4000 Notifies control system of button press (1 - 4000).
High/1 = Button being pressed
Low/0 = Button not being pressed
Digital Input Signal Descriptions
INPUT DESCRIPTION
fb 1 through fb 4000 Notifies panel of button press (1 - 4000). This can
represent that the button was pressed, or can be
an actual device feedback, e.g., that power was
turned on.
Analog Output Signal Descriptions
OUTPUT DESCRIPTION
an_act 1 through an_act 4000 Notifies control system of an action (1 - 4000). Any
value from 0 through 65535
Analog Input Signal Descriptions
INPUT DESCRIPTION
an_fb 1 through an_fb 4000 Notifies panel of analog action (1 - 4000).
Serial Input Signal Descriptions
INPUT DESCRIPTION
text-01 through text-999 Notifies panel of text string (1 - 999). Also called
indirect text.
Device Extenders
Device extenders provide additional logic and functionality to a device. The Poll
Manager and Sleep/Wake Manager symbols are device extenders for touchpanels.
Poll Manager takes the touchpanel on and off line during polling by the control
system. Sleep/Wake Manager suspends and restores operation of the touchpanel. For
additional information about Device Extenders, refer to the latest version of the
Crestron SIMPL Windows Symbol Guide (Doc. 6120), or the on-line help included
with SIMPL Windows.
Example Program
An example program for the TPS-2000L is available from the Crestron FTP site
(ftp://ftp.crestron.com/Examples
). Search for the file TPS2000L.ZIP that contains
the example program, associated files and a README.TXT file that describes the
program.
Programming with Crestron VisionTools
Pro-e
Crestron VisionTools
Pro-e (VT Pro-e), a Windows
-based software for designing
touchpanel screens, permits the creation of unlimited control screen variations
incorporating two and three-dimensional graphics and text as well as sounds
(recorded as WAV files). A set of pages, which make up a project, can be designed
for each TPS-2000L touchpanel application. Each page contains objects such as
custom control graphics, two and three-dimensional buttons, sliders, and digital
readouts which allow the user to interface with the control system via join numbers.
Unjoined objects are not interfaced with the system and thus cannot initiate any
functions. The completed and compiled project is uploaded to the touchpanel and
programmed into the flash PROM via the File | Upload Project command. The
Operations Guide – DOC. 5972A 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L • 21
