5 Inch Lectern/Wall Mount Touchpanel Crestron Isys
TPS-2000L
3. As shown after this step, select the NET ID of the TPS-2000L
touchpanel and then click OK. The “Touch Panel Transfer” window
appears (refer to the subsequent graphic).
“Select Network ID” Window
NOTE: When transferring any Cresnet file (touchpanel project/firmware), lower the
port speed baud rate to 38400 to match the Cresnet bus speed when transferring
through a control system.
“Touch Panel Transfer” Window
Each time a project is
selected using the Browse
command, that project is
added to the File Name
drop-down list. This makes
it convenient to recall
projects without need to
browse to a directory. To
delete the list click Clear
History.
All Files in Project: sends
the entire project.
Only Changed Files:
sends only the files that are
different from those that
are currently stored in the
panel. Note that if any
pages in the panel are not
present in the project, those pages will be deleted from the panel.
Additional choices include Do not send graphic files and Do not send sound files.
These are often very large files that take a long time to load.
4. Click Browse. The “Open” window appears as shown in the following
illustration.
34 • 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L Operations Guide – DOC. 5972A
