Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-3
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
5.3.1 Top Chassis Assembly
Refer to Figure 5.1 for Exploded View
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Not Pictured
1
1
4
2
2
1
8
8
8
1
1
1
1
1
5
20
1
1
1
Front Assembly
Chassis
Heatsink Assembly
Paper Shroud
Channel 1 B-L Switch Assembly
Power Transformer 120VAC 60Hz Domestic
Power Transformer 230VAC 50Hz E17CE
Transformer Plate
#8 Nylon Shoulder Washer
#8 Int Star Washer
Screw, 8-32 x 2.75 MSCR PNHD Zinc
Fan Assembly
Top Cover
Back Panel Assembly
Fuse, 1A 3AG 1.25 x .25
Control PWA
1/4 PC BD Support
star washer
Screw, 6-32 x.31 TORX PNHD STAR
Channel 2 B-L Switch Assembly
Bottom Cover
Insulator, 11 x 15 Transformer
Cable Tie Mount
see Section 5.3.3
F12621-3
see Section 5.3.3
see Section 5.3.3
see Section 5.3.6
see Section 5.3.8
D 8867-0
see Section 5.3.5
D 8874-6
D8876-1
F12588-4
A10099-5
A10094-6
A10089-10844
see Section 5.3.7
see Section 5.3.7
F12544J6
see Section 5.3.4
A10285-10
see Section 5.4
C 6032-4
included with screw
103433-70605
see Section 5.3.6
F12609-8
D8249-1
C 6918-4
