Crown Macro-Tech MA-3600VZ Service Manual

MA-3600VZ Service Manual
Parts 5-68
130366-1 Rev. A
©2000 Crown International, Inc.
Q42861-7 VZ Switch PWA (D 7272-4 PWB) Parts List
Capacitors
C16 C 2821-4 10pF
C17 C 2821-4 10pF
C18 C 3411-3 200pF
C19 C 3728-0 10µF
C20 C 3411-3 200pF
C21 C 6683-4 4700pF
C22 D 7595-8 6900µF
C23 D 7595-8 6900µF
C24 D 7595-8 6900µF
C25 D 7595-8 6900µF
Diodes
D17 C 3549-0 1N961B 10V
D18 C 6578-6 1N4735 6.2V
Resistors
R01 C 7421-8 2.5K .5W
R02 C 7441-6 90.9K 1%
R03 C 5707-2 100K 1%
R04 C 7440-8 27.4K 1%
R06 C 5707-2 100K 1%
R07 C 7441-6 90.9K 1%
R08 C 5707-2 100K 1%
R09 C 7440-8 27.4K 1%
R11 C 5707-2 100K 1%
R12 C 6317-9 953 1%
R13 C 6317-9 953 1%
R14 C 4850-1 1K 1%
R15 C 4850-1 1K 1%
R16 C 4225-6 470K
R17 C 3620-9 68K
R18 C 2631-7 10K
R19 C 3939-3 4.7K
R20 C 2632-5 15K
R21 C 2875-0 1.2K
R22 C 4167-0 43K
R23 C 3622-5 200K
R24 C 6090-2 62K
R25 C 3804-9 2K
R26 C 7654-4 3.9M
R27 C 5975-5 680
R28 C 2883-4 100K
Integrated Circuits
U03 C 7444-0 LM393
U04 C 7445-7 LM555
U05 C 4345-2 LM339
Transistors
Q03 D 2961-7 2N3859A, SEL
Misc.
C 3451-9 8 Pin IC Socket
