Crown Macro-Tech MA-3600VZ - Q42851-8 Display PWA (D 7617-0 PWB) Parts List

MA-3600VZ Service Manual
Parts 5-62
130366-1 Rev. A
©2000 Crown International, Inc.
Q42851-8 Display PWA (D 7617-0 PWB) Parts List
Capacitors
C501 C601 C 6802-0 .47µF Ax
C502 C602 C 6806-1 .01µF Ax
C503 C603 C 6806-1 .01µF Ax
C507 C607 C 6809-5 220pF
C701 C 6804-6 .1µF Ax
C702 C 6804-6 .1µF Ax
C703 C 6804-6 .1µF Ax
C704 C 6804-6 .1µF Ax
Diodes
D501 D601 C 3181-2 1N4148
D502 D602 C 3181-2 1N4148
D503 D603 C 3181-2 1N4148
LEDs
E501 E601 C 7863-1 Grn SPI/IOC
E502 E602 C 4342-9 Amber ODEP
E701 C 4342-9 Amber Enable
Transistors
Q501 Q601 C 3625-8 PNP 2N4125
Q502 Q602 D 2961-7 NPN 2N3859A Sel
Q503 Q603 D 2961-7 NPN 2N3859A Sel
Q504 Q604 C 3625-8 PNP 2N4125
Resistors
R501 R601 A10266-1051 1M
R502 R602 A10266-3331 33K
R503 R603 A10266-2741 270K
R504 R604 A10266-1031 10K
R505 R605 A10266-1022 1K .5W
R506 R606 A10266-2222 2.2K .5W
R507 R607 A10266-3332 33K .5W
R508 R608 A10266-1351 1.3M
R509 R609 A10266-7551 7.5M
R510 R610 A10266-7551 7.5M
R511 R611 A10266-4741 470K
R512 R612 A10266-2221 2.2K
R513 R613 A10266-1522 1.5K .5W
R514 R614 A10266-1001 10
R701 A10266-1522 1.5K .5W
R703 A10266-2031 20K
R704 A10266-1031 10K
R705 A10266-1031 10K
R706 A10266-2031 20K
ICs
U501 U601 C 4345-2 LM339
U502 C 5070-7 TL072
U701 C 8518-0 MC78L15ACP +15V
U702 C 8519-8 MC79L15ACP -15V
Misc.
J3 C 4508-5 16 Pin Header
Spacers (5) A10101-2 LED Spacer
