Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-71
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Capacitors
C00 C 2288-6 .001µF
C16 C 2821-4 10pF
C17 C 2821-4 10pF
C18 C 3411-3 200pF
C19 C 3728-0 10µF
C20 C 3411-3 200pF
C21 C 6683-4 4700pF
C22* D 7595-8 6900µF
C23* D 7595-8 6900µF
C24* D 7595-8 6900µF
C25* D 7595-8 6900µF
Diodes
D17 C 3549-0 1N961B 10V
D18 C 6578-6 1N4735 6.2V
D19 C 8855-6 BYV72-150
D20 C 8855-6 BYV72-150
Ferrite Bead
FB00 C 9156-0 30 Ohm, 10MHz
FB01 C 9156-0 30 Ohm, 10MHz
FB02 C 9156-0 30 Ohm, 10MHz
Transistors
Q00 C 9927-2 IRF540
Q01 C 9927-2 IRF540
Q02 C 9927-2 IRF540
Q03 D 2961-7 2N3859A, SEL
Integrated Circuits
U00 C 6901-0 MOC8021
U03 C 7444-0 LM393
U04 C 7445-7 LM555
U05 C 4345-2 LM339
Resistors
R00 A10266-1011 100
R01 C 7852-4 2.4K 5W
R02 A10265-90921 90.9K 1%
R03 A10265-10031 100K 1%
R04 A10265-27421 27.4K 1%
R06 A10265-10031 100K 1%
R07 A10265-90921 90.9K 1%
R08 A10265-10031 100K 1%
R09 A10265-27421 27.4K 1%
R11 A10265-10031 100K 1%
R12 A10265-95301 953 1%
R13 A10265-95301 953 1%
R14 A10265-10011 1K 1%
R15 A10265-10011 1K 1%
R16 A10266-4741 470K
R17 A10265-24921 24.9K 1%
R18 A10265-10021 10K 1%
R19 A10265-4721 4.7K
R20 A10266-1531 15K
R21 A10266-1221 1.2K
R22 A10266-4331 43K
R23 A10266-2041 200K
R24 A10266-6231 62K
R25 A10266-2021 2K
R26 A10266-3951 3.9M
R27 A10266-6811 680
R28 A10265-10031 100K 1%
Misc.
P00 C 9527-0 6 Pin Header
P01 C 7592-6 4 Pin Header
C 3451-9 8 Pin IC Socket
D 8174-1 Board
* These components do not come with the Q43298-1
PWA.
Q43298-1 VZ Switch PWA (D 8174-1 PWB) Parts List
