Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-21
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Q42893-0 Output PWA (P10316-1 PWB) Parts List
Capacitors
C01 C 3978-1 .047µF
C02 C 8426-6 .1µF
C03 C 8426-6 .1µF
C04 C 6806-1 .01µF
C05 C 6806-1 .01µF
C06 C 6806-1 .01µF
C07 C 6807-9 .001µF
C08 C 8577-6 68pF
C12 C 6809-5 220pF
C13 C 7502-5 .47µF
C15 C 6809-5 220pF
C16 C 8426-6 .1µF
Diodes
D01 C 2851-1 1N4004
D02 C 2851-1 1N4004
D03 C 2851-1 1N4004
D04 C 2851-1 1N4004
D05 C 8383-9 MR822
D06 C 8383-9 MR822
D07 C 8383-9 MR822
D08 C 8383-9 MR822
D09 C 2851-1 1N4004
D10 C 2851-1 1N4004
D11 C 2851-1 1N4004
D12 C 2851-1 1N4004
Inductors
L00 D 7701-2 2.5µH
L01 C 3510-2 470µH
L02 C 3510-2 470µH
Transistors
Q01 C 8159-3 2SC4029
Q05 C 8186-6 2SA1553
Q12 C 8159-3 2SC4029
Q16 C 8186-6 2SA1553
Q17 C 8508-1 2SC3298B
Q18 D 2962-5 MPSA18
Q19 C 8509-9 2SA1306B
Resistors
R00 C 5236-2 130
R01 C 2872-7 100
R02 C 8544-6 8.2 .5W
R03 C 3583-9 .33 5W
R04 C 3583-9 .33 5W
R05 C 3583-9 .33 5W
R06 C 3583-9 .33 5W
R07 C 3583-9 .33 5W
R08 C 3583-9 .33 5W
R09 C 7779-9 22
R10 C 2872-7 100
R11 C 6625-5 5.6 5W
R12 C 1001-4 2.7 1W
R13 C 5236-2 130
R14 C 1001-4 2.7 1W
R15 C 3583-9 .33 5W
R16 C 3583-9 .33 5W
R17 C 3583-9 .33 5W
R18 C 3583-9 .33 5W
R19 C 3583-9 .33 5W
R20 C 3583-9 .33 5W
R21 C 8544-6 8.2 .5W
R22 C 7779-9 22
R23 C 6844-2 250 POT
R24 C 4300-7 13K
R25 C 2628-3 2.2K
R26 C 6844-2 250 POT
R27 C 6495-3 390
R28 C 4300-7 13K
R29 C 6402-9 51
R30 C 6626-3 102 1%
R31 C 6625-5 5.6 5W
R35 C 3612-6 1 .5W
R36 C 3612-6 1 .5W
Miscellaneous
(2) C 7057-0 10 Pin Header
