Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-55
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc. Parts 5-55
130366-1 Rev. A
MA-3600VZ Service Manual
Q42859-1 Control PWA (P10291-6 PWB) Parts List
Capacitors
C801 C 5234-7 .047µF
C802 C 5234-7 .047µF
Resistors
R801 C 3753-8 10 Ohm
R802 C 3753-8 10 Ohm
Fuse
F801 C 3065-7 1 Amp
Relays
K801 C 7891-2 24V 10A Relay
K802 C 7891-2 24V 10A Relay
Diodes
D801 C 2851-1 1N4004
D802 C 2851-1 1N4004
Transistors
Q801 C 3625-8 2N4125
Q802 C 3625-8 2N4125
Misc.
P801-P815 C 7817-7 Tab, .25 Faston
J5 C 4508-5 16 Pin IC Socket
(2) C 5060-6 Fuse Clip
Capacitors
C801 C 5234-7 .047µF
C802 C 5234-7 .047µF
C803 C 8897-8 .01µF
C804 C 8897-8 .01µF
Diodes
D801 C 2851-1 1N4004
D802 C 2851-1 1N4004
D803 C 3549-0 1N961B 10V
Fuse
F801 C 3065-7 1 Amp
Relays
K801 C 9787-0 30A, 24V
K802 C 9787-0 30A, 24V
Transistors
Q801 C 3625-8 2N4125
Q802 C 3625-8 2N4125
Resistors
R801 A10266-1001 10 Ohm
R802 A10266-1001 10 Ohm
R803 A10266-4731 47K
R804 A10266-8231 82K
R805 A10266-1331 13K
R806 A10266-1331 13K
R807 A10266-2231 22K
R808 A10266-1331 13K
R809 A10266-1331 13K
IC's
U801 C 7444-0 LM393
Misc.
(2) C 5060-6 Fuse Clip
J5 C 4508-5 16 Pin IC Socket
P801-P815 C 7817-7 Tab, .25 Faston
P816, P817 C 7873-0 2 Pin Header
(1) C 3451-9 8 Pin IC Socket
Q43124-9 Control PWA (D 8172-5 PWB) Parts List
