Crown Macro-Tech MA-3600VZ - Q43363-3 Control PWA (D 8696-3 PWB) Parts List

Parts 5-57
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Q43363-3 Control PWA (D 8696-3 PWB) Parts List
Capacitors
C801 C 5234-7 .047µF
C802 C 5234-7 .047µF
C803 C 8897-8 .01µF
C804 C 8897-8 .01µF
C805 C 6807-9 .001µF
Diodes
D801 C 2851-1 1N4004
D802 C 2851-1 1N4004
D803 C 3549-0 1N961B 10V
D804 C 3181-2 1N4148
D805 C 3181-2 1N4148
D806 C 9596-5 1N5237B 8.2V
D807 C 9929-8 TL431ACLP
Fuse
F801 C 3065-7 1 Amp
Relays
K801 C 9787-0 30A, 24V
K802 C 9787-0 30A, 24V
Transistors
Q801 C 3625-8 2N4125
Q802 C 3625-8 2N4125
Q803 C 3625-8 2N4125
Q804 C 3786-8 MPS4250A
Q805 C 3786-8 MPS4250A
Resistors
R801 A10266-1001 10 Ohm
R802 A10266-1001 10 Ohm
R803 A10266-1821 1.8K
R804 A10266-8231 82K
R805 A10266-1331 13K
R806 A10266-1331 13K
R807 A10266-2231 22K
R808 A10266-1331 13K
R809 A10266-1331 13K
R810 A10266-2231 22K
R811 A10266-4741 470K
R812 A10266-8211 820 Ohm
R813 A10266-6221 6.2K
R814 C 9928-0 51.1K
R815 C 9639-3 4.99K
R816 A10266-1041 100K
R817 A10266-3941 390K
R818 A10266-1041 100K
R819 A10266-3941 390K
IC's
U801 C 7444-0 LM393
Misc.
(2) C 5060-6 Fuse Clip
J5 C 4508-5 16 Pin IC Socket
P801-P815 C 7817-7 Tab, .25 Faston
P816, P817 C 7873-0 2 Pin Header
(1) C 3451-9 8 Pin IC Socket
