Crown Macro-Tech MA-3600VZ Service Manual

MA-3600VZ Service Manual
Parts 5-70
130366-1 Rev. A
©2000 Crown International, Inc.
Capacitors
C00 C 2288-6 .001µF
C16 C 2821-4 10pF
C17 C 2821-4 10pF
C18 C 3411-3 200pF
C19 C 3728-0 10µF
C20 C 3411-3 200pF
C21 C 6683-4 4700pF
C22* D 7595-8 6900µF
C23* D 7595-8 6900µF
C24* D 7595-8 6900µF
C25* D 7595-8 6900µF
Diodes
D17 C 3549-0 1N961B 10V
D18 C 6578-6 1N4735 6.2V
D19* C 8855-6 BYV72-150
D20* C 8855-6 BYV72-150
Ferrite Bead
FB00 C 9156-0 30 Ohm, 10MHz
FB01 C 9156-0 30 Ohm, 10MHz
FB02 C 9156-0 30 Ohm, 10MHz
Transistors
Q00* C 8516-4 IRF641
Q01* C 8516-4 IRF641
Q02* C 8516-4 IRF641
Q03 D 2961-7 2N3859A, SEL
Integrated Circuits
U03 C 7444-0 LM393
U04 C 7445-7 LM555
U05 C 4345-2 LM339
Resistors
R00 C 2872-7 100
R01 C 7852-4 2.4K 5W
R02 A10265-90921 90.9K 1%
R03 C 5707-2 100K 1%
R04 A10265-27421 27.4K 1%
R06 C 5707-2 100K 1%
R07 A10265-90921 90.9K 1%
R08 C 5707-2 100K 1%
R09 A10265-27421 27.4K 1%
R11 C 5707-2 100K 1%
R12 C 6317-9 953 1%
R13 C 6317-9 953 1%
R14 A10265-10011 1K 1%
R15 A10265-10011 1K 1%
R16 C 4225-6 470K
R17 C 3620-9 68K
R18 C 2631-7 10K
R19 C 3939-3 4.7K
R20 C 2632-5 15K
R21 A10266-1221 1.2K
R22 C 4167-0 43K
R23 C 3622-5 200K
R24 C 6090-2 62K
R25 C 3804-9 2K
R26 A10266-3951 3.9M
R27 A10266-6811 680
R28 C 5707-2 100K
Misc.
P00 C 9527-0 6 Pin Header
P01 C 7592-6 4 Pin Header
C 3451-9 8 Pin IC Socket
D 8174-1 Board
* These components do not come with the Q43181-9
PWA.
Q43181-9 VZ Switch PWA (D 8174-1 PWB) Parts List
