Crown Macro-Tech MA-3600VZ Service Manual

Parts 5-9
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
5.3.4 Back Panel Assembly
Refer to Figure 5.4 for Exploded View
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
4
2
2
1
1
1
1
2
2
2
1
1
10
2
2
1
1
1
2
Dual Binding Post
Screw, 8-32 x .37 RDHD MSCR
#8 Int Star Washer, Black
Standard PIP Assembly
Power Cord, NEMA TT-30P Plug, Domestic
Power Cord, HAR 230VAC 15A Plug, E17CE
Strain Relief
Edge Connector
Circuit Breaker, 15A, Domestic
Circuit Breaker, 8A, E17CE
#4 Int Star Lockwasher
Screw, 4-40 x .62 RDHD
Jumper, 4 Position Ground
Back Panel
Washer, #6 Int Star
Screw, 6-32 x .312 Pan HD T15 Taptite
Aluminum Spacer
PWB, PIP Interconnect
Cable W/Terminals
Daisy Ribbon Cable
2-Position Jumper
C10184-7
A10086-70806
A10094-5
See Section 5.3.9
D8247-5
D8844-9
C7315-2
C 6821-0
C10169-8
C10171-4
A10094-2
A10086-10410
D8855-5
F12864-9
A10094-3
C 9491-9
A10100-7
101240-1
D7623-8
D8573-4
F12812-8
